Manufacturer Part Number:
P860
Watt:
860
Technical Details
Efficiency(%):
99.5
Manufacturer Part Number: P860-4NMDMBX
Module Compatibility: 2x 72 cell modules
Rated DC Input Power: 860W
Current (Isc): 22.0A
Maximum Output Current: 18ADC
Maximum Output Voltage: 80VDC
Connector Type: MC4, Dual input for independently connected modules
Peak Efficiency: 99.5%
Compliance: Photovoltaic Rapid Shutdown System (NEC 2014, 2017, 2020); EMC (FCC Part15 Class A, IEC61000-6-2, IEC61000-6-3); Safety (IEC62109-1 (class II safety), UL1741); Material (UL-94 V-0, UV Resistant); RoHS.
Shipping weight: 2.6 lb
Shipping dimensions: 15 x 15 x 11 in
Box Qty: 10
