Manufacturer Part Number:
SA-Limitless-15K-10Y
Watt:
15000
Input Voltage (Vdc):
500 Volt
Output Voltage (Vac):
120 Volt
Phase:
1-phase
Technical Details
Inverter Type:
0.965
BATTERY AGNOSTIC
LEAD ACID or LI-ION battery chemistry support.
Any battery with nominal DC voltage of 48V.
275A continuous battery charging output.
3-Stage charging curve with equalization.
Close loop communication with most high-end lithium batteries.
19.5KW SOLAR INPUT POWER
x3 built-in MPPT for max DC coupled power of 19.5KW
Max AC coupled solar input of 19.2KW
Max combined solar input of 38.4KW
15KW OUTPUT POWER OFF-GRID
Continuous AC power of 15KW with PV
Continuous AC power of 12KW from batteries only
Max grid sell output of 34.2KW
Supports 120V,240V, and 208V connections
FULL GENERATOR COMPATIBILITY
Supports 220V, 240V, and 208V generators on grid breaker
Up to 24KW generators on GEN breaker
Standby generator connection for whole-home backup
Two wire for automatic generator start only
