Manufacturer Part Number:
SG350HX-US
Input Voltage (Vdc):
1500 Volt
Output Voltage (Vac):
800 Volt
Phase:
3-phase
Inverter Type:
Grid-tied
Technical Details
Efficiency:
0.9902
Multi-MPPT String Inverter for 1500VDC System
350kW, 3phase, 800VAC Out, 1500VDC In, AFCI, 12x MPPT inputs, Voltage range of 600V-1500V, and MC4-Evo2 DC connection
HIGH YIELD
20A per string, compatible with 500Wp+ module
Data exchange with tracker system, improving yield
Up to 16 MPPTs with max. efficiency 99%
GRID SUPPORT
SCR?1.15 stable operation in extremely weak grid
Reactive power response time <30ms
Compliant with global grid code
LOW COST
Q at night function, save investment
Power line communication (PLC)
Smart IV Curve diagnosis, active O&M
PROVEN SAFETY
2 strings per MPPT, no fear of string reverse connection
Integrated DC switch, automatically cut off the fault
24h real-time AC and DC insulation monitoring
